High temperature insulation paper
for various applications
Versatile applications of SoliPaper™
SoliPaper™ is ideally suited for applications that require further processing, such as laminating, die-cutting, rolling and folding. Some common applications include:
- Insulation in non-ferrous molten metal processing or as backup linings for melting tanks
- Thermal insulation in heat shields for the automotive industry
- As a filler for expansion joints between prefabricated shapes and IFB linings
- Gaskets for household appliances, such as boilers and heaters
- Flexible sealing in fire-resistant applications for windows and doors
- Interlayering during soldering and brazing
- General technical insulation solutions
Benefits of SoliPaper™
- High tensile strength and resilience thanks to its high fibre index
- Low density for a smooth and uniform paper
- Excellent processability for further machining such as cutting and punching
- Wide range of chemical compositions for applications up to 1,600°C
- Durable and flexible with excellent temperature stability
Why we choose
SoliPaper™ products
Quinsis offers a wide range of high-quality insulation paper specially designed for high-temperature applications. Thanks to our expertise, we can supply various insulation materials, but we prefer the reliability and performance of SoliPaper™. This lightweight, flexible yet strong material is ideal for a wide range of industrial applications.
Available sizes of SoliPaper™
SoliPaper™ is available in thicknesses from 1 to 10 mm and is supplied in standard and jumbo rolls:
- Jumbo rolls: standard width of 1,200 mm
- Standard rolls: available in widths of 610 mm or double width 1,220 mm
Our SoliPaper™ range
The SoliPaper™ range consists of several product groups, each suitable for specific applications and temperature ranges:
- Standard Grade RCF
- SoliPaper™ X-grade: refractory ceramic fibre paper with a classification temperature up to 1,260°C
- SoliPaper™ ZR-grade: refractory ceramic fibre paper with a classification temperature up to 1,430°C
- Special Grade SoliPaper™
- SoliPaper™ CR-grade: specially designed for applications in extreme environments
- SoliPaper™ PCW: a unique blend of 80% mullite fibre and 20% SoliWool™ HA fibre, with a classification temperature up to 1,600°C
- Low Bio Persistence (LBP) Grade
- SoliPaper™ ULS®: standard LBP paper available in both standard and jumbo rolls
- SoliPaper™ LOWPAC: an industrial grade with lower density and tighter thickness specifications, ideal for high-volume gasket production
